Electronics SMT Nitrogen Generator

Lub tshuab hluav taws xob SMT nitrogen generator yog ib qho khoom siv nitrogen uas tsim los rau saum npoo mount tshuab siv hauv kev tsim khoom siv hluav taws xob. Cov cuab yeej siv tshuab siv lub tshuab nqus cua siab swing adsorption (PSA), siv cov cua compressed raws li cov khoom siv los ua kom muaj siab - purity nitrogen ntawm - qhov chaw, uas yog muab ncaj qha mus rau reflow ncu, yoj lub tshuab soldering, thiab lwm yam khoom siv, muab cov roj inert ruaj khov tiv thaiv cov txheej txheem soldering.

Piv nrog rau cov kua nitrogen ib txwm siv lossis lub tog raj kheej nitrogen, ntawm -qhov chaw nitrogen tshem tawm cov kev thauj mus los thiab kev cia khoom, muab cov nqi roj tuaj yeem tswj tau ntau dua thiab ua haujlwm ruaj khov dua. Cov cuab yeej siv no tau ua haujlwm ntev - lub sijhawm ua haujlwm thoob plaws ntau lub chaw tsim khoom siv hluav taws xob, txhawb nqa qhov kev xav tau ntau ntxiv ntawm SMT kab.

Txoj Cai thiab Cov Qauv

Cov cuab yeej ua haujlwm ntawm lub siab viav vias adsorption txoj cai siv carbon molecular sieves. Compressed cua nkag mus rau hauv lub adsorption yees, qhov twg cov pa oxygen, dej vapor, thiab lwm yam impurity gases yog adsorbed los ntawm molecular sieves, tso cai rau nitrogen los ntawm cov khoom roj. Lub kaw lus siv ob lub adsorption yees ua haujlwm sib hloov kom ua tiav cov khoom siv nitrogen tas li.

Cov txheej txheem ua tiav suav nrog cov khoom hauv qab no:

• Cua Compression thiab Purification System: Muab cov huab cua huv, qhuav compressed
• Adsorption Tower Assembly: Muaj cov pa roj carbon molecular sieves rau nitrogen -oxygen cais
• Nitrogen Buffer Tank: Stabilizes tso zis siab thiab ntws
• PLC Tswj System: Ua kom muaj kev ua haujlwm tsis siv neeg, hloov kho purity, thiab lub tswb tsis raug

Lub kaw lus nta cov qauv tsim nrog me me hneev taw, tso cai rau kev txhim kho yooj yim hauv SMT kev cob qhia lossis cov khoom siv mezzanines.

Technical Specifications

• Purity thiab Flow Rate: Purity theem tuaj yeem hloov kho raws li qhov xav tau ntawm SMT kab, nrog rau kev khiav hauj lwm ntau ntawm 99.99% - 99.999%, ua tau raws li qhov xav tau ntawm cov hlau lead- cov txheej txheem dawb soldering.
• Kev siv hluav taws xob: Kev siv hluav taws xob hauv ib chav tsev ntawm cov roj tsim tau txo qis dua 30% piv rau cov qauv siv roj, nrog cov nqi khiav haujlwm kwv yees li ib - tsib rau ib -feem peb ntawm cov kua nitrogen.
• Qhov kub thiab txias: Cov cuab yeej tsim los ua haujlwm hauv qhov kub thiab txias ntawm 0℃txog 45 degree. Lub qhov hluav taws xob nitrogen kub tseem nyob ze rau ntawm chav tsev kub thiab tuaj yeem txuas ncaj qha rau cov khoom siv soldering yam tsis muaj cua sov ntxiv lossis cua txias.

Cov ntawv thov kev lag luam

Cov khoom siv no feem ntau yog siv hauv SMT cov kab ntau lawm hauv kev lag luam hluav taws xob tsim khoom. Cov ntawv thov tseem ceeb suav nrog:

• Nitrogen tiv thaiv rau reflow ncu
• Wave soldering txheej txheem
• Selective soldering khoom
• Laser jet ball placement systems

Kev tiv thaiv Nitrogen zoo txo ​​qhov sib koom ua ke oxidation, txhim kho cov yam ntxwv ntawm ntub dej, thiab txo cov pob qij txha thiab kev cuam tshuam ntawm kev sib txuas, uas sawv cev rau cov txheej txheem tseem ceeb rau kev txhim kho cov txiaj ntsig zoo.

Cov ntawv pov thawj thiab cov qauv

Cov khoom tsim thiab kev tsim khoom ua raws li cov qauv hauv qab no:

• ISO 9001 Kev Tswj Xyuas Kev Tswj Xyuas Kev Ua Haujlwm Zoo
• TS EN ISO 8573-1 Compressed Cua Zoo Standards
• ASME Pressure Vessel Standards (yeem)

Lub siab tseem ceeb-cov khoom siv bearing tuaj yeem tsim tau raws li ASME cov qauv raws li cov neeg siv khoom thov, ua tau raws li kev xav tau ntawm kev lag luam thoob ntiaj teb.

Kev xa tawm qhov project

Cov txheej txheem xa khoom yog npaj raws li cov neeg siv khoom tshwj xeeb thiab qhov project, feem ntau suav nrog cov theem hauv qab no:

1. Kev lees paub qhov yuav tsum tau ua: Txhais purity, ntws tus nqi, siab, thiab lwm yam kev qhia raws li SMT kab tsis
2. System Design: Muab cov duab kos duab kos duab thiab cov phiaj xwm kev teeb tsa, pib tsim khoom raws li kev pom zoo
3. Manufacturing: Lub sij hawm ntau lawm teem raws li cov khoom configuration thiab cov txheej txheem yuav tsum tau, nrog rau lub sij hawm tshwj xeeb xa khoom tau lees paub hauv daim ntawv cog lus
4. Factory Testing: Txhua chav ua haujlwm ua haujlwm tsis tu ncua txhawm rau txheeb xyuas qhov ua tau zoo
5. Ntawm -Tsev Kev Txhim Kho thiab Kev Ua Haujlwm: Cov kws tshaj lij engineers muab kev taw qhia kev teeb tsa thiab ua tiav kev koom ua ke nrog SMT cov cuab yeej
6. Kev cob qhia tus neeg ua haujlwm: Hauv - kev cob qhia ntawm qhov chaw ua kom cov neeg ua haujlwm nkag siab txog cov kev xav tau ntawm kev saib xyuas niaj hnub

Customization Muaj peev xwm

Cov kev daws teeb meem Customized yog muaj raws li cov neeg siv khoom tshwj xeeb:

• Purity thiab txaus tus nqi tsim raws li cov kab ntau lawm specifications
• Cov kev xaiv tswj muaj xws li kev tswj hwm hauv zos lossis kev saib xyuas tej thaj chaw deb
• Gas kev sib txuas interfaces tuaj yeem hloov kho kom haum rau SMT cov khoom siv tshwj xeeb
• Zuag qhia tag nrho qhov ntev tuaj yeem hloov kho raws li qhov chaw teeb tsa

Kev Pabcuam thiab Kev Pabcuam

• Kev Pabcuam Kev Pabcuam: Muab ua ntej- kev sib tham txog kev muag khoom thiab cov lus qhia txog kev sib koom ua ke
• Tom qab -Kev Pabcuam Muag: Kev taw qhia kev teeb tsa thiab kev cob qhia tus neeg ua haujlwm tau muab rau thaum xa khoom; pab pawg neeg pab txhawb nqa muaj nyob rau tej thaj chaw deb lossis ntawm -kev pab ntawm qhov chaw thaum muaj teeb meem ua haujlwm
• Cov Khoom Muag Khoom Muag: Ntev- lub sijhawm muaj cov khoom qub nrog rau cov lim dej, molecular sieves, thiab li qub
• Kev Ntsuam Xyuas Chaw Taws Teeb: Xaiv cov qauv txhawb kev saib xyuas cov chaw taws teeb thiab kuaj xyuas qhov yuam kev

Cov hluav taws xob hluav taws xob SMT nitrogen generator sawv cev rau cov khoom lag luam paub tab zoo txuas ntxiv los ntawm Shenger Gas rau cov khoom siv hluav taws xob tsim khoom. Shenger Gas tau sau ntau xyoo ntawm kev tsim thiab tsim kev paub hauv kev lag luam roj sib cais, nrog rau kev tsom mus rau kev ua haujlwm ruaj khov thiab kev saib xyuas yooj yim. Peb tseem cog lus tias yuav muab cov kev daws teeb meem roj sib cais uas muaj kev ntseeg siab nyob rau hauv cov kev xav tau ntawm engineering.
