Pharmaceutical Nitrogen Generator
Lub tshuab hluav taws xob tshuaj nitrogen yog ib qho ntawm -site nitrogen system tsim tshwj xeeb rau kev tsim tshuaj. Tsis zoo li cov kua nitrogen tso tsheb hlau luam lossis cov khoom siv lub tog raj kheej, cov cuab yeej siv no siv cov tshuab Pressure Swing Adsorption (PSA) los tsim cov nitrogen ncaj qha rau ntawm qhov chaw siv, tshem tawm cov khoom tsis ruaj khov, cov nqi thauj mus los siab, thiab kev pheej hmoo ntawm kev nyab xeeb.
Hauv kev tsim tshuaj, nitrogen feem ntau hu ncaj qha rau cov khoom siv tshuaj. Shenger Gas kws tshuaj nitrogen generators feature ib tug tag nrho stainless hlau qauv nrog daim iav - polished adsorption ntauwd interiors thiab orbital welded kev twb kev txuas mus tshem tawm cov chaw tuag. Lub kaw lus ua raws li cov qauv cGMP thiab tuaj yeem xa mus rau hauv ob qho tib si cais thiab tsis yog -chaw cais.
Txoj Cai & Qauv
Lub kaw lus ua haujlwm ntawm PSA thev naus laus zis. Ob lub adsorption yees uas muaj cov pa roj carbon molecular sieve ua haujlwm sib hloov. Thaum ua ntej-kho cua compressed nkag mus rau hauv ib lub pej thuam, oxygen thiab noo noo yog adsorbed, cia nitrogen hla dhau. Thaum saturated, lub kaw lus hloov mus rau tus pej thuam thib ob thaum thawj zaug rov tsim dua.
Core modules:
- Kev kho cua: Coalescing filters, tub yees tshuab ziab khaub ncaws, thiab activated carbon lim kom roj-dawb, qhuav inlet cua
- Kev sib cais: Ob lub stainless hlau yees, pneumatic li qub, thiab tswj nrog precision molecular sieve filling
- Buffer & faib: Stabilizes siab; tuaj yeem ntxiv precision lim, regulators, thiab flowmeter
Technical Specifications
|
Parameter |
Ntau yam |
|---|---|
|
Nitrogen Purity |
95% - 99.999% (kho tau) |
|
Tus nqi ntws |
1-500 Nm³ / h (customizable) |
|
Dew Point |
Tsawg dua lossis sib npaug rau -40℃(tsawg dua lossis sib npaug rau -70℃xaiv tau) |
|
Qhov hluav taws xob siab |
0.4-0.8MPa |
Ua haujlwm kub: 5 ℃ - 45 ℃ ambient; inlet cua Tsawg dua los yog sib npaug li 35℃rau kev pom zoo.
Kev siv hluav taws xob: Ntawm 99.9% purity, kwv yees li 0.4 - 0.6 kWh / Nm³. Zog-Txuag kev tswj xyuas kev ua haujlwm raws li qhov xav tau tiag tiag.
|
Yam khoom |
Specification |
|---|---|
|
Fais fab mov |
220V / 380V, 50 / 60Hz |
|
Tswj |
PLC tsis siv neeg nrog cov chaw taws teeb pib / nres |
|
Interface |
Touchscreen qhia purity, ntws, siab, xwm txheej |
|
Tswb |
Tsawg purity, siab abnormality, tus kheej - kuaj mob |
|
Suab nrov |
Tsawg dua lossis sib npaug li 75 dB (1m nrug) |
Cov ntawv thov kev lag luam
Cov kws tshuaj nitrogen generator pab rau cov theem tseem ceeb:
- Khoom noj khoom haus: Cov khoom siv thauj khoom thiab kev tiv thaiv rau cov khoom sib tov, cov ntsiav tshuaj xovxwm, cov tshuaj ntsiav tshuaj
- Sterile khoom: Sterile nitrogen rau kev npaj tshuab, sau kab, lyophilizers
- Biopharmaceuticals: Nitrogen daim pam rau fermenters thiab cia tank
- API & TCM rho tawm: Daim pam rau cov kuab tshuaj rov qab thiab oxidation -sensitive intermediates
- Ntim: Nitrogen flushing rau tshuab blister thiab lub raj mis kab
Cov ntawv pov thawj
Shenger Gas kws tshuaj nitrogen generators ua raws li:
- TS EN ISO 8573-1 Cov qauv huab cua purity compressed
- ASME: Siab hlab ntsha code ua raws (yeem)
- cGMP: Ua raws li cov ntaub ntawv pov thawj (DQ / IQ / OQ / PQ)
- FDA: Cov ntaub ntawv pov thawj tiv tauj muaj
Kev xa tawm qhov project
- Tsim: Cov cuab yeej layout thiab P&ID raws li tus neeg siv khoom tsis muaj thiab qhov chaw nyob
- Manufacturing: Traceable cov ntaub ntawv rau vuam thiab molecular sieve loading; ntsuas ntsuas calibration
- Kev Xeem: Lub Hoobkas lees txais kev xeem nrog cov lus qhia ntxaws
- Kev thauj mus los & kev teeb tsa: Cov ntaub ntawv ntoo lossis cov hnab ntim khoom ntim; ntawm - kev qhia kev teeb tsa ntawm qhov chaw
Kev kho kom haum
- Purity: 95% - 99.999% tus qauv tsim kom tsis txhob muaj hluav taws xob pov tseg
- Configuration: Qhib thav duab, kaw tag nrho, lossis chav huv huv- ua ke
- Tswj: Zog-txuag cov tswv yim nrog rau VFD thiab compressor kev koom ua ke
- Khoom siv: 316L stainless hlau los yog electropolished tubing rau corrosive ib puag ncig
Kev Pabcuam & Txhawb
- Validation: Ua kom tiav 4Q cov ntaub ntawv rau GMP kev tshuaj ntsuam xyuas
- Kev cob qhia: Kev cob qhia neeg ua haujlwm thiab kev cob qhia tu
- Teb: Ntawm - qhov chaw pabcuam hauv 48 teev rau cov haujlwm hauv tsev; tseem ceeb spare qhov chaw stocked
Shenger Gas tshwj xeeb hauv PSA nitrogen tiam nrog kev siv tshuaj ntau hauv kev lag luam. Txhua lub tshuab hluav taws xob tshuaj nitrogen yog tsim los rau cov txheej txheem kev nyab xeeb, cov ntaub ntawv kev ncaj ncees, thiab kev ua raws li kev cai. Rau cov tshuaj nitrogen uas haum rau koj cov txheej txheem tshuaj, tiv tauj peb nrog koj cov kev cai tshwj xeeb.
